Stäubli is entering a new performance class with its TS2 SCARA series. The completely redesigned 4-axis machine with proprietary JCS drive technology facilitates ultra-short cycle times and high repeatability. It also has a revolutionary encapsulated design which opens up new possibilities for use in sensitive environments. It is piloted by the generic CS9 controller that also controls TX2 6-axis robots.
The fast and compact TS2-60 robot has special features, such as a maximum payload of 8.4 kg with a 620 mm reach.
Up to 620 mm
Up to 8.4 kg
|Degrees of freedom||4|
|Load capacity||8.4 kg|
|Stroke||200 mm or 400 mm (option)|
|Repeatability X-Y||± 0,01 mm|
|Repeatability Z||± 0,004 mm|
|Repeatability R-Z||± 0,002°|
|Protection class - EN 60529||Up to IP65 with ball screw cover and bellows|
|Attachment methods||Floor or ceiling|
